Stand Alone Access Controller - HID Prox Card Reader & Keypad Controller - Single or Double Doors - Waterproof IP68
Stand Alone Access Controller - HID Prox Card Reader & Keypad Controller - Single or Double Doors - Waterproof IP68
Deguard
Couldn't load pickup availability
SLK-DAC-KP002
Item number: 7885
The Stand Alone Access Controller - HID Prox Card Reader & Keypad Controller is made with 2 relays for controlling up to to 2 doors It is suitable for mounting either indoor or outdoor environments. It is housed in a strong, sturdy and vandal proof Zinc Alloy with an internal tamper alarm. This outdoor / indoor waterprooof keypad is built with ease of installation and ease of use in mind. Using a HID proximity card or pin code or a combination of both for access. Fully programmable for up to 2000 users. It can control the Lock , a Security Alarm, Door Bell Alarm, and also can connect with Exit Buttons and Door Contacts.
There are 7 working modes:
- Wiegand Reader.
- Standalone for single door.
- Standalone for two doors.
- With external reader for two doors.
- Two units interlocked for two doors.
- Anti-passback for single door.
- Anti-passback for two door.
- One Master code
- Two Manager cards
Specifications:
| Application | Outdoor / Indoor |
| Input Voltage | AC/DC 12V |
| User Capacity |
2000 users Can be controlled by Prox Card, PIN Code or Combination of Prox Card and PIN |
| Programmable | Easily programmable at the lock |
| Tamper Alarm | Built in light dependent resistor (LDR) for anti tamper |
| Alarm | Built in buzzer |
| Keyboard | back-lit for night accessibility , the back light can be set to Normal ON, Normal OFF or Human-Approach ON. |
| Card Reading Distance | 3-6 cm |
| Idle Current | <25mA |
| Lock Output Load | <1A |
| Alarm Output Load | <1A |
| Ring bell load | <1A |
| Card reading distance | 40mm Max |
| Card Frequency: | 125KHz for EM and HID |
| Card transmission format | 26-37 bit wiegand |
| Keypad transmission format | 4bit, 8bit and Virtual card number |
| Card type |
EM and HID |
| Enclosure material | Strong Zinc Alloy Electroplated anti-vandal case |
| Operating Temperature | -49°~131° F ( -45°C～55° C) |
| Operating Humidity | 10%～95% non-condensing |
| Environment | Conforms to IP68 Waterproof Standards |
Downloads
Complete Installation, Wiring and Programming Instructions
