Simplex - 1011 - Mechanical Pushbutton Cylindrical Lever Lock - 2¾" Backset - Satin Chrome - Grade 1
Simplex - 1011 - Mechanical Pushbutton Cylindrical Lever Lock - 2¾" Backset - Satin Chrome - Grade 1
Simplex
Couldn't load pickup availability
SLK-KABA-101126D41
Item Number: 4153
Simplex Mechanical Pushbutton Locks eliminate problems and costs associated with issuing, controlling, and collecting keys and cards. The Simplex 1000 Series provides exterior access by combination, while allowing free egress. This mechanical lock, with knob option, eliminates the material and labor expense of battery replacements. Knob combination entry only. NO KEY OVERRIDE.
Features:
- Single access code—one easy-to-manage code for all users
- Lock is easily programmed via keypad without removing lock from the door
- Factory-handed for left-hand doors; easily field reversible
- A cost effective access control solution
Specifications:
|
Construction: |
Heavy-duty cylindrical lock housing with cast front housing; unified trim plate; cast knobs |
|
Locking Device: |
Cylindrical ½" (13 mm) throw latch, floating face plate 2¾" (70 mm) backset (UL listed) |
|
Numeric Keypad: |
Vandal resistant, solid metal pushbuttons |
|
Handing: |
Factory-handed for left-hand doors; easily field reversible |
|
Finish: |
Satin Chrome 26D (626) |
|
Key Override: |
NONE |
|
Backset: |
2¾" (70 mm) |
|
Latch: |
½" (13 mm) throw latch |
|
Minimum Stile Recommended: |
5" (127 mm) |
|
Strike: |
Standard strike plate; ASA strike plate |
|
Door Preparation: |
Easily installs on wood or metal doors. ASA 161 door preparation with additional through bore holes required. |
|
Door Thickness: |
1⅜" (35 mm) to 2¼" (57 mm)—Pre-assembled to accommodate 1⅝" (41 mm) to 2" (51 mm) |
|
Durability: |
D.O.D. Compliant 5220.22M for supplemental access control; weather resistant |
|
Certification: |
BAA / NAFTA Certified |
|
Fire Rating: |
3-hour UL/ULC fire rating for "A" label doors |
|
Warranty: |
3 years manufacturer warranty |
Downloads:
Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact DORMA KABA directly at 1-800-849-8324 or visit their support page here. Once you have the ticket contact SLK Hardware for the return.
