ABRITES - AVDI - VN015 - VAG - Odometer recalibration for VAG vehicles

SLK-ABRITES-AVDI-VN015
Item Number: 5971

With the help of the VN015, you will be able to perform calibrations of the mileage in Volkswagen/Audi/Seat/Skoda/Bentley/Lamborghini and even some Porsche vehicles. It is very helpful when you need to replace a module that contains mileage information about the vehicle you are working on. Here is what you can do using this special function listed below:

•


Mileage recalibration:

• For Audi A6/A7 (4G) and A8 (D4) and VW Touareg 7P produced from 2010 until 2017 BY OBDII.
• The function works with UDS dashboards.
• Reading and updating internal control module configuration memory by diagnostics.
• Extracting and recalibration security access codes, PIN, component security bytes, current unit mileage values by K-line, CAN bus, and UDS.

Cluster CAN:

• With this function, you can establish a diagnostic session with the instrument cluster using KWP2000 over TP2.0 or UDS.
• You can Read/Update the odometer values. Supported types are: - VDO/MM/Visteon -2007 (CAN TP2.0)- VDO with NEC μC 2009+ (CAN UDS)- JCI with NEC μC
• and 95320 EEPROM (CAN UDS)- Magneti Marelli with 9S12 μC (CAN UDS)- A8(4H)/A7(4G)/A6(4G)/Touareg(7P) with 95320 EEPROM (CAN UDS)

Cluster K-Line:

• With this function, you can establish a diagnostic session with the Instrument cluster via K-Line
• (KWP1281 or KWP2000); You can Read/update the odometer value; Read PIN code; Read/Update ConfData; Read ROM/Flash from the Instrument cluster;
• Automatic removing of "DEF error" for Audi A4 instrument cluster BOSCH RB8. Supported types are:- VDO66/86, Motometer- External Immobilizer - LT,
• VW GOL, VW O GOL( Kostal ), Siemens 6 PIN HC05 Immo/TMS- Audi A4 B5 with/without board computer -1997- Audi A6 -1997- Audi A8 -1999- Magneti Marelli - Shadow 1/2/3/Direct-
• VW Sharan/Galaxy -2000- Audi A4 Bosch RBx/RB4/RB4 Crypto/RB8 Crypto 2004+- Golf 4 Bosch RBx- VW Phaeton/Touareg, Bentley Continental,
• Porsche Cayenne- Seat Exeo Bosch RB8 Crypto 2008+- Lamborghini Gallardo -2005/2005+

Read/Update ConfData:

• (VAG-EDC15x, VAG-ME7.1.1, VAG-ME7.1, VAG-ME7.5, VAG-Cartronic ME7.8.)
• Extracting Security access code / PIN (EDC15, ME7.x, VAG-Cartronic ME7.8) - Extracting Component security bytes
• (EDC15, ME7.x, VAG-Cartronic ME7.8)- Mileage Calibration (EDC15, EDC16)

N.B. Please note that you will require an AVDI interface with an active AMS in order to use this special function.
