ABRITES - AVDI - PN009 - Engine control unit advanced diagnostic

SLK-ABRITES-PN009
Item Number: 9578

PN009 is a special function dedicated to reading and updating the Configuration data, reading and updating the flash, making IMMO OFF, resetting service intervals, and changing the PIN codes of Engine Control Units of different ECUs in Peugeot/ Citroën vehicles.

Below you can find a list of what you can do with different ECU's:

Allows you to read and write the EEPROM of:
EDC15, EDC17(BOOT MODE), SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;
Reading and calibrating the mileage in the dashboard of EDC16, EDC17(BOOT MODE), SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;
Allows you to read and change the PIN of
EDC15, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;
Allows you to modify the service intervals of
EDC15, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;
Allows you to read and write the EEPROM of
EDC15 Engine ECUs and make Immo OFF, as well as after-sales and edit service list.
Supported models are all models using the following electronic cotrol units: EDC15, EDC16, EDC17, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806.

N.B. Please note that you will require an AVDI interface with an active AMS in order to use this special function. Absolutely no tokens required.

ALL SALES OF ABRITES PRODUCTS HARDWARE AND SOFTWARE ARE FINAL!
