ABRITES - AVDI - FN020 - PIN and Key Manager for FCA vehicles

SLK-ABRITES-AVDI-FN020

The FN020 - PIN and Key Manager for FCA vehicles.

The FN020 update has added support for key programming for FIAT vehicles with MOPAR BCM units such as FIAT 500 2020+.

Includes all previous functionality from special function FN019 as well as all previous versions of the key programming functionality for FCA vehicles.

More Information Below:

Key programming. Transponders/Keys preparation. BCM - Configuration data read and update, PIN, component protection data display. Remote control programming. Includes support for Alfa Romeo Giulia/Stelvio and vehicles with mechanical Megamos AES keys. (FIAT Tipo, Egea, 500X, Toro, Argos, Cronos, Jeep Renegade, Jeep Wrangler)

BCM Read/Update ConfData by OBDII.

Supported units:

• BCM Delphi (93C66) - NOTE: PIN Code is required!
• BCM Marelli (912DG128, 3K91D)
• BCM Marelli (9S12DG256, 1K79X)
• BCM Marelli (NEC 70F3237/70F3378,95160)
• BCM Marelli (NEC 70F3633,95320)- BCM Siemens (9S12DG128)
• BCM from Delphi with NEC 70F3632/70F363
• Remote Frequency HUB direct connection via internal CAN for new models.

Transponder maker - Preparing transponder by dump of immobilizer to be ready for key programming.
Key learning - by OBDII key programming for various models Fiat, Alfa, Lancia - Alfa 147, Mito; Fiat Freemont, 500, 500L, 500X, Bravo, Grande punto, Croma, Doblo, Ducato, Fiorino, Idea, Palio,
Panda, Stilo; Lancia Thesis, Delta; Jeep Cherokee KL 2013+; CHRYSLER 200,300, PT Cruiser, Town & Country, Sebring; DODGE - Nitro, Viper (2013+), Dart, Dakota, Aspen, Avenger,
Caliber, Caravan, Challenger, Charger, Durango, Journey, Magnum, RAM, RAM (Mexico), RAM 1500, 2500, 3500, 4500, 5500; JEEP - Commander, Compass, Grand Cherokee, Wrangler,
Liberty (2008+) Reading of the PIN codes of the new Chrysler/Dodge/Jeep models such as the Chrysler Pacifica from 2017+
PIN code reading from the Wireless Control Module (WIN/WCM) or Radio Frequency Hub (RFH) for Chrysler, Dodge, and Jeep vehicles(2006-2011)
Remote control programming by OBDII: Alfa 147; Fiat Bravo, Chroma, Idea, Palio, Panda, Punto, Stilo, Doblo, Ducato; Lancia Thesis

N.B. Please note that you will require an AVDI interface with an active AMS in order to use this special function. Absolutely no tokens required.
