Cal Royal - Single Cylinder Gate Latch - Standard Duty - IC Core - Satin Chrome - Grade 2

Cal Royal - Single Cylinder Gate Latch - Standard Duty - IC Core - Satin Chrome - Grade 2

Cal-Royal

$119.22 USD
$143.06 USD $119.22 USD
Sale Sold out
Shipping calculated at checkout.

Standard Duty Gate Latches for Light Commercial & Residential Applications. Accepts Small-format interchangeable core (SFIC) core included.


Features:

  • The dead-locking latch bolt is retracted by a key from outside or by thumb turn on inside. Otherwise always locked
  • Meets The Buy American Act
  • Keyway: Schlage "C" Keyway 6 pin (Standard)
  • Interchangeable core, for Best, Arrow, and Falcon
  • Exceeds 400,000 cycles
  • Sturdy, all-steel deadbolt and mechanism
  • Cast Iron solid housing
  • 2-1/2" diameter tapered cylinder guard and metal insert, turn free with any removal attempt

Specifications:

Collection Cal-Royal
Function Single Cylinder Gate Latch
Deadlocking latch bolt retracted by key from outside or by thumb turn on inside. Otherwise always locked (2 ¾” backset)
Finish 626 - Satin Chrome
Backset 2-3/8"
Door Thickness 1-3/8" (35mm)- 1-3/4" (45mm) Adjustable
Strike  1 ⅛” X 2 ¾” square corner.
Cylinder 6 pin solid brass "C" keyway standard.
Keyway Schlage "C"
Certification Conforms with ANSI A 156.2 Series 4000, Standard Duty GRADE 2



Downloads:



View full details
