Marks USA - 5PD - LifeSaver Single Cylinder Mortise Behavioral Health Paddleset - Push / Pull - Anti-Ligature - Dormitory - 2-3/4" Backset - Satin Stainless - Grade 1

Marks USA - 5PD - LifeSaver Single Cylinder Mortise Behavioral Health Paddleset - Push / Pull - Anti-Ligature - Dormitory - 2-3/4" Backset - Satin Stainless - Grade 1

Marks USA

Precio habitual $413.19 USD
Precio habitual $588.93 USD Precio de oferta $413.19 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

SLK-MRK-5PDFW-32D-G3

The PD Series LifeSaver Anti-Ligature Mortise Hospital Push/Pull Paddlesets are the best alternative to knob or lever handles. Makes opening a latched door as natural as opening an unlatched one – just push or pull in the direction in which the door swings.

Features:

  • Functional, modern design with variable mounting positions
  • Short throw angle allows for easy push/pull action to open doors even when hands are not free
  • Standard 32D finish
  • Universal assemblies can be push/pull vertical up or down
  • Easily reversible configuration for push or pull styles
  • Door Thickness is self adjusting for thicker doors
  • ANSI-A156.2, Grade 1
  • ADA Compliant
  • Non-Handed


Specifications:

Construction Mortise Hospital Push and Pull Paddleset
Function F13 - Dormitory - Outside keyed, Inside Thumbturn
Paddle Extruded aluminum
Backset  2-3/4"
Strike

#9035, 4-7/8" ASA curved lip strike

Door Thickness 1-3/4” door thickness, self adjusting for thicker doors
Mounting

Variable mounting positions

Handing Non-Handed Easily reversible configuration for push or pull styles
Finish US32D Satin Stainless Steel
Door prep Government standard #161 door prep
Cylinder: G3 - Less Cylinder
Certifications ANSI-A156.2, Grade 1. ADA Compliant
Manufacturer's Warranty Limited Lifetime Warranty



Download Installation Instructions Here
